Specifications
Enclosure size
D, E, F
Table 8.19 Soft Charge Fuses
1) 170M fuses from Bussmann shown use the -/80 visual indicator, -TN/80 Type T, -/110 or TN/110 Type T indicator fuses of the same size and
amperage may be substituted for external use.

8.5 General Torque Tightening Values

For fastening hardware described in this manual, use the torque values in Table 8.20. These values are not intended for
fastening IGBTs. See the instructions included with those replacement parts for correct values.
Shaft Size
M4
M5
M6
M8
M10
M12
Table 8.20 Torque Values
MG37A322
Installation Manual
Bussmann PN
FNQ-R-1
Driver Size Torx/Hex [mm]
T-20/7
T-25/8
T-30/10
T-40/13
T-50/17
18/19
Danfoss A/S © Rev. 04/2015 All rights reserved.
Rating
1 A, 600 V
Torque [Nm]
1.0
2.3
4.0
9.6
19.2
19
Torque [in-lbs]
10
20
35
85
170
170
8
105
8
