Specifications
•
The adjustable frequency drive is protected against ground faults on motor terminals U, V, W.
Frame size
Voltage [V]
Current, RMS [A]
Peak current [A]
Response time [ms]
Settling time - reactive current control [ms]
Settling time - harmonic current control
(filtering) [ms]
Overshoot - reactive current control [%]
Overshoot - harmonic current control [%]
Table 8.4 Power Ranges (LHD with AF)
Grid conditions
Supply voltage
AC line voltage low/line drop-out:
During low AC line voltage or a line drop-out, the filter continues until the intermediate circuit voltage drops below the minimum
stop level, which corresponds to 15% below the filter lowest rated supply voltage. Full compensation cannot be expected at AC
line voltage lower than 10% below the filter lowest rated supply voltage. If AC line voltage exceeds the filter highest rated
voltage, the filter continues to work but harmonic mitigation performance is reduced. The filter does not cut out until AC line
voltages exceed 580 V.
Supply frequency
Max. imbalance temporary between line phases
where mitigation performance is kept high.
Max THDv pre-distortion
Harmonic mitigation performance
THiD
Individual harmonic mitigation ability:
2nd
4th
5th
7th
8th
10th
11th
13th
14th
16th
17th
19th
20th
22nd
23rd
25th
Total current of harmonics
The filter is performance tested to the 40th order
