Introduction
1 Contactor
2 RFI filter
3 Line power AC power input terminals
Figure 1.6 Frame Size F18 Options Cabinet
*The options cabinet is not optional for the LHD. The ancillary equipment is stored in the cabinet.
MG37A322
Installation Manual
1
6
5
4
4
5
Danfoss A/S © Rev. 04/2015 All rights reserved.
2
3
Circuit breaker or disconnect (if purchased)
AC line power/line fuses (if purchased)
1 1
11
