Status Messages
No. Text
1317 Option SW in slot C0 is not supported (not
allowed)
1318 Option SW in slot C1 is not supported (not
allowed)
1379 Option A did not respond when calculating
platform version
1380 Option B did not respond when calculating
platform version
1381 Option C0 did not respond when calculating
platform version.
1382 Option C1 did not respond when calculating
platform version.
1536 An exception in the application-oriented control is
registered. Debug information written in LCP.
1792 DSP Watch Dog is active. Debugging of power part
data, motor-oriented control data not transferred
correctly.
2049 Power data restarted
2064–2072 H081x: Option in slot x has restarted
2080–2088 H082x: Option in slot x has issued a power-up wait
2096–2104 H983x: Option in slot x has issued a legal power-
up wait
2304 Could not read any data from power EEPROM
2305 Missing SW version from power unit
2314 Missing power unit data from power unit
2315 Missing SW version from power unit
2316 Missing lo_statepage from power unit
2324 Power card configuration is determined to be
incorrect at power-up
2325 A power card has stopped communicating while
line power is applied
2326 Power card configuration is determined to be
incorrect after the delay for power cards to
register.
2327 Too many power card locations have been
registered as present.
2330 Power size information between the power cards
does not match.
2561 No communication from DSP to ATACD
2562 No communication from ATACD to DSP (state
running)
2816 Stack overflow control board module
2817 Scheduler slow tasks
2818 Fast tasks
2819 Parameter thread
2820 LCP stack overflow
2821 Serial port overflow
2822 USB port overflow
2836 cfListMempool too small
3072–5122 Parameter value is outside its limits
MG37A322
Installation Manual
No.
5123
5124
5125
5126
5376–6231 Out of memory
Table 7.1 Internal Fault, Code Numbers
ALARM 39, Heatsink sensor
No feedback from the heatsink temperature sensor.
The signal from the IGBT thermal sensor is not available on
the power card. The problem could be on the power card,
on the gate drive card, or the ribbon cable between the
power card and gate drive card.
WARNING 40, Overload of digital output terminal 27
Check the load connected to terminal 27 or remove the
short-circuit connection. Check parameter 5-00 Digital I/O
Mode and parameter 5-01 Terminal 27 Mode.
WARNING 41, Overload of digital output terminal 29
Check the load connected to terminal 29 or remove the
short-circuit connection. Check parameter 5-00 Digital I/O
Mode and parameter 5-02 Terminal 29 Mode.
WARNING 42, Overload of digital output on X30/6 or
overload of digital output on X30/7
For X30/6, check the load connected to X30/6 or remove
the short-circuit connection. Check parameter 5-32 Term
X30/6 Digi Out (MCB 101).
For X30/7, check the load connected to X30/7 or remove
the short-circuit connection. Check parameter 5-33 Term
X30/7 Digi Out (MCB 101).
ALARM 45, Ground fault 2
Ground fault.
Troubleshooting
•
•
•
ALARM 46, Power card supply
The supply on the power card is out of range.
There are three power supplies generated by the switch
mode power supply (SMPS) on the power card: 24 V, 5 V,
±18 V. When powered with 24 V DC with the MCB 107
option, only the 24 V and 5 V supplies are monitored.
When powered with three phase AC line voltage, all three
supplies are monitored.
Danfoss A/S © Rev. 04/2015 All rights reserved.
Text
Option in slot A: Hardware incompatible with
control board hardware
Option in slot B: Hardware incompatible with
control board hardware.
Option in slot C0: Hardware incompatible with
control board hardware.
Option in slot C1: Hardware incompatible with
control board hardware.
Check for proper grounding and loose
connections.
Check for proper wire size.
Check the motor cables for short circuits or
leakage currents.
