4 Specifications

4.1

Absolute Maximum Ratings

These specifications indicate levels where permanent damage to the module can occur. Functional operation is not ensured
under these conditions. Operation at absolute maximum conditions for extended periods can adversely affect long-term
reliability of the module.
SYMBOL
VBAT and VIO
Digital I/O
RF pins
Analog pins
Temperature
4.2

Handling Ratings

T Storage temperature range
stg
Electrostatic discharge (ESD)
V
ESD
performance:
(1) JEDEC document JEP155 states that 500-V HBM allows safe manufacturing with a standard ESD control process.
(2) JEDEC document JEP157 states that 250-V CDM allows safe manufacturing with a standard ESD control process.
4.3

Power-On Hours

T up to 85°C, assuming 20% active mode and 80% sleep mode
Ambient
4.4

Recommended Operating Conditions

Function operation is not ensured outside this limit, and operation outside this limit for extended periods can adversely affect
long-term reliability of the module.
SYMBOL
VBAT and VIO
Operating temperature
Ambient thermal slew
(1) Operating temperature is limited by crystal frequency variation.
(2) To ensure WLAN performance, the ripple on the power supply must be less than ±300 mV.
Copyright © 2014, Texas Instruments Incorporated
CONDITION
Respect to GND
Respect to GND
Human body model (HBM), per ANSI/ESDA/JEDEC
(1)
JS001
Charged device model (CDM),
(2)
per JESD22-C101
CONDITIONS
(1)
(2)
CONDITION
Battery mode
–
Submit Documentation Feedback
MIN TYP
–0.5 3.3
–0.5 –
–0.5
–0.5
–40
All pins
MIN TYP
2.3 3.3
–20 25
–20
CC3200MOD
SWRS166 – DECEMBER 2014
MAX UNIT
3.8 V
VBAT + 0.5 V
2.1 V
2.1 V
+85 °C
MIN MAX UNIT
–40 85 °C
–1.0 1.0 kV
–250 250 V
POH
17,500
MAX UNIT
3.6 V
70 °C
20 °C/minute
Specifications 23
