PARAMETER PARAMETER
NUMBER
I2
I3
I4
I7
I8
I9
4.11.2.8 UART
The CC3200 device includes two UARTs with the following features:
• Programmable baud-rate generator allowing speeds up to 3 Mbps
• Separate 16 x 8 TX and RX FIFOs to reduce CPU interrupt service loading
• Programmable FIFO length, including 1-byte deep operation providing conventional double-buffered
interface
• FIFO trigger levels of 1/8, 1/4, 1/2, 3/4, and 7/8
• Standard asynchronous communication bits for start, stop, and parity
• Line-break generation and detection
• Fully programmable serial interface characteristics
– 5, 6, 7, or 8 data bits
– Even, odd, stick, or no-parity bit generation and detection
– 1 or 2 stop-bit generation
• RTS and CTS hardware flow support
• Standard FIFO-level and End-of-Transmission interrupts
• Efficient transfers using μDMA
– Separate channels for transmit and receive
– Receive single request asserted when data is in the FIFO; burst request asserted at programmed
FIFO level
– Transmit single request asserted when there is space in the FIFO; burst request asserted at
programmed FIFO level
• System clock is used to generate the baud clock.
Copyright © 2014, Texas Instruments Incorporated
Table 4-14. Camera Parallel Port Timing Parameters
PARAMETER NAME
pCLK Clock frequency
T Clock period
clk
t Clock low period
LP
t Clock high period
HT
D Duty cycle
t RX data setup time
IS
t RX data hold time
IH
Submit Documentation Feedback
MIN MAX
2
1/pCLK
T /2
clk
T /2
clk
45% to 55%
2
2
CC3200MOD
SWRS166 – DECEMBER 2014
UNIT
MHz
ns
ns
ns
ns
ns
