CC3200MOD
SWRS166 – DECEMBER 2014
General Pin Attributes
Pin Alias Use Select as
Wakeup
Source
GPIO0 I/O No
GPIO30 I/O No
GPIO1 I/O No
16 Terminal Configuration and Functions
Table 3-2. Pin Multiplexing (continued)
Config Muxed Dig. Pin Mux Config
Addl with Reg
Analog JTAG
Mux
User config
not GPIO_PAD_CONFIG_0
No
required (0x4402 E0A0)
(8)
User config
GPIO_PAD_CONFIG_3
not
No 0
required
(0x4402 E118)
(8)
GPIO_PAD_CONFIG_1
No No
(0x4402 E0A4)
Submit Documentation Feedback
Function
Dig. Pin Signal Name Signal
Mux Description
Config
Mode
Value
General-Purpose
0 GPIO0
I/O
12 UART0_CTS UART0 Clear To
Send Input (Active
Low)
6 McAXR1 I2S Audio Port
Data 1 (RX/TX)
7 GT_CCP00 Timer Capture Port
9 GSPI_CS General SPI Chip
Select
10 UART1_RTS UART1 Request
To Send O (Active
Low)
3 UART0_RTS UART0 Request
To Send O (Active
Low)
4 McAXR0 I2S Audio Port
Data 0 (RX/TX)
General-Purpose
0 GPIO30
I/O
9 UART0_TX UART0 TX Data
2 McACLK I2S Audio Port
Clock O
3 McAFSX I2S Audio Port
Frame Sync
4 GT_CCP05 Timer Capture Port
7 GSPI_MISO General SPI MISO
General-Purpose
0 GPIO1
I/O
3 UART0_TX UART0 TX Data
4 pCLK (PIXCLK) Pixel Clock From
Parallel Camera
Sensor
6 UART1_TX UART1 TX Data
7 GT_CCP01 Timer Capture Port
www.ti.com
Pad States
(1) (2)
Signal LPDS Hib nRESET = 0
Direction
I/O Hi-Z Hi-Z Hi-Z
I Hi-Z Hi-Z Hi-Z
I/O Hi-Z
I Hi-Z
I/O Hi-Z
O 1
O 1
I/O Hi-Z
I/O Hi-Z Hi-Z Hi-Z
O 1
O Hi-Z
O Hi-Z
I Hi-Z
I/O Hi-Z
I/O Hi-Z Hi-Z Hi-Z
O 1
I Hi-Z
O 1
I Hi-Z
