CC3200MOD
SWRS166 – DECEMBER 2014
9.2.2 Tape and Reel Information
REEL DIMENSIONS
Package
Device
Drawing
CC3200MODR1M2AMOBR MOB
CC3200MODR1M2AMOBT MOB
62 Mechanical Packaging and Orderable Information
Reel
Diameter
A0
B0
K0
W
P1
Reel Width (W1)
QUADRANT ASSIGNMENTS FOR PIN 1 ORIENTATION IN TAPE
Q1
Q2
Q3 Q4
Pocket Quadrants
Reel
Pins SPQ
Diameter (mm)
63 1000 330.0±2.0
63 250 330.0±2.0
Submit Documentation Feedback
TAPE DIMENSIONS
K0 P1
Cavity A0
Dimension designed to accommodate the component width
Dimension designed to accommodate the component length
Dimension designed to accommodate the component thickness
Overall width of the carrier tape
Pitch between successive cavity centers
Sprocket Holes
Q1 Q2
User Direction of Feed
Q3 Q4
Reel
A0 B0
Width W1
(mm) (mm)
(mm)
44.0 17.85±0.10 20.85±0.10
44.0 17.85±0.10 20.85±0.10
Copyright © 2014, Texas Instruments Incorporated
www.ti.com
B0 W
K0 P1 W
(mm) (mm) (mm)
2.50±0.10 24.00±0.10 44.00±0.30
2.50±0.10 24.00±0.10 44.00±0.30
Pin1
Quadrant
Q3
Q3
