CC3200MOD
SWRS166 – DECEMBER 2014
6.2
Bill of
Materials(1)
PART
QUANTITY
REFERENCE
1
U1
1
E1
1
C2
1
L1
(1) Resistors are not shown here. Any resistor of 5% tolerance can be used.
6.3
Layout Recommendations
6.3.1 RF Section (Placement and Routing)
Being wireless device, the RF section gets the top priority in terms of layout. It is very important for the RF
section to be laid out correctly to get the optimum performance from the device. A poor layout can cause
low output power, EVM degradation, sensitivity degradation and mask violations.
52
Applications, Implementation, and Layout
VALUE
MANUFACTURER
CC3200MOD
Texas Instruments
2.45-GHz Ant
Taiyo Yuden
Murata Electronics North
1.0 pF
America
Murata Electronics North
3.6 nH
America
Figure 6-2. RF Section Layout
Submit Documentation Feedback
PART NUMBER
CC3200MODR1M2AMOB
AH316M245001-T
GJM1555C1H1R0BB01D
LQP15MN3N6B02D
Copyright © 2014, Texas Instruments Incorporated
www.ti.com
DESCRIPTION
SimpleLink Wi-Fi MCU
Module
ANT Bluetooth WLAN
®
ZigBee
WIMAX
CAP CER 1 pF 50 V
NP0 0402
INDUCTOR 3.6 NH
0.1 NH 0402
