4.10 WLAN RF Characteristics

WLAN Receiver Characteristics
T = +25°C, V = 2.3 to 3.6 V. Parameters measured at module pin on channel 7 (2442 MHz)
A BAT
PARAMETER
Sensitivity
(8% PER for 11b rates, 10% PER for
(1)
11g/11n rates)(10% PER)
Maximum input level
(10% PER)
(1) Sensitivity is 1-dB worse on channel 13 (2472 MHz).
4.10.1 WLAN Transmitter
T = +25°C, V = 2.3 to 3.6 V. Parameters measured at module pin on channel 7 (2442 MHz)
A BAT
PARAMETERS
Max RMS Output Power measured at 1 dB
from IEEE spectral mask or EVM
Transmit center frequency accuracy
(1) Channel-to-channel variation is up to 2 dB. The edge channels (2412 and 2472 MHz) have reduced TX power to meet FCC emission
limits.
30 Specifications
CONDITION (Mbps)
1 DSSS
2 DSSS
11 CCK
6 OFDM
9 OFDM
18 OFDM
36 OFDM
54 OFDM
MCS7 (Mixed Mode)
802.11b
802.11g
Characteristics(1)
CONDITIONS
1DSSS
2DSSS
11CCK
6OFDM
9OFDM
18OFDM
36OFDM
54OFDM
MCS7 (Mixed Mode)
Submit Documentation Feedback
MIN TYP MAX
–94.7
–92.6
–87.0
–89.0
–88.0
–85.0
–79.5
–73.0
–69.0
–3.0
–9.0
MIN TYP
17
17
17.25
16.25
16.25
16
15
13.5
12
–20
Copyright © 2014, Texas Instruments Incorporated
www.ti.com
UNITS
dBm
MAX UNIT
dBm
20 ppm
