CC3200MOD
SWRS166 – DECEMBER 2014
1.2

Applications

• Internet of Things (IoT)
• Cloud Connectivity
• Home Automation
• Home Appliances
• Access Control
• Security Systems
• Smart Energy
1.3

Description

Start your design with the industry's first programmable FCC, IC, CE, and Wi-Fi Certified Wireless
microcontroller (MCU) module with built-in Wi-Fi connectivity. Created for the Internet of Things (IoT), the
SimpleLink CC3200MOD is a wireless MCU module that integrates an ARM Cortex-M4 MCU, allowing
customers to develop an entire application with a single device. With on-chip Wi-Fi, Internet, and robust
security protocols, no prior Wi-Fi experience is required for faster development. The CC3200MOD
integrates all required system-level hardware components including clocks, SPI flash, RF switch, and
passives into an LGA package for easy assembly and low-cost PCB design. The CC3200MOD is provided
as a complete platform solution including software, sample applications, tools, user and programming
guides, reference designs, and the TI E2E™ support community
The applications MCU subsystem contains an industry-standard ARM Cortex-M4 core running at 80 MHz.
The device includes a wide variety of peripherals, including a fast parallel camera interface, I2S, SD/MMC,
UART, SPI, I2C, and four-channel ADC. The CC3200 family includes flexible embedded RAM for code
and data; ROM with external serial flash bootloader and peripheral drivers; and SPI flash for Wi-Fi network
processor service packs, Wi-Fi certificates, and credentials.
The Wi-Fi network processor subsystem features a Wi-Fi Internet-on-a-chip™ and contains an additional
dedicated ARM MCU that completely off-loads the applications MCU. This subsystem includes an 802.11
b/g/n radio, baseband, and MAC with a powerful crypto engine for fast, secure Internet connections with
256-bit encryption. The CC3200MOD supports station, access point, and Wi-Fi Direct™ modes. The
device also supports WPA2 personal and enterprise security and WPS 2.0. The Wi-Fi Internet-on-a-chip
includes embedded TCP/IP and TLS/SSL stacks, HTTP server, and multiple Internet protocols. The
power-management subsystem includes integrated DC-DC converters supporting a wide range of supply
voltages. This subsystem enables low-power consumption modes, such as the hibernate with RTC mode
requiring less than 7 μA of current.
PART NUMBER
CC3200MODR1M2AMOB
(1) For more information, see
2 Module Overview
Table 1-1. Module Information
Section 9, Mechanical Packaging and Orderable Information.
Submit Documentation Feedback
• Internet Gateway
• Industrial Control
• Smart Plug and Metering
• Wireless Audio
• IP Network Sensor Nodes
• Wearables
(1)
PACKAGE
MOB (63)
BODY SIZE
20.5 mm × 17.5 mm
