ISO 13849-1
Information to be provided
Design rationale (e.g. faults considered, faults
excluded)
Measures against reasonably foreseeable misuse
Dated reference to this part of ISO 13849 (that is
"ISO 13849-1:2006");
Category (B, 1, 2, 3, or 4)
Performance level (a, b, c, d, or e)
Use of de-energization (see ISO 13849-2)
Measures for controlling the effects of voltage
breakdown, voltage variations, overvoltage, under
voltage
Measures for controlling or avoiding the effects of
the physical environment (for example,
temperature, humidity, water, vibration, dust,
corrosive substances, electromagnetic
interference and its effects)
Program sequence monitoring must be used with
SRP or CS containing software to detect defective
program sequences
Measures for controlling the effects of errors and
other effects arising from any data communication
process (see IEC 61508-2:2000, 7.4.8)
Failure detection by automatic tests
Computer-aided design tools capable of
simulation or analysis
Simulation
Safety-related specification for machine control
Definition of the control architecture
Software descriptions
Function block modeling
Encoding comments in the code
Encoding re-reading sheets
Correspondence matrix
UM1845 - Rev 4
ISO 13849-1 Part-Clause
10 Technical documentation
11 Information for use
G.2 Measures for the control of
systematic failures
G.2 Measures for the control of
systematic failures
G.2 Measures for the control of
systematic failures
G.3 Measures for avoidance of
systematic failures
-
App. J, tab.J.1 (SW)
App. J, tab.J.1 (SW)
App. J, tab.J.1 (SW)
App. J, tab.J.1 (SW)
App. J, tab.J.1 (SW)
ISO 13849-1 / ISO 13849-2
STM32F2 Series
IEC 61508 document
STM32F2 Series Safety Manual
End user responsibility
STM32F2 Series Safety Manual
End user responsibility
End user responsibility
Software User Guide
(End user responsibility because in charge of
implementing software-based diagnostics)
SW requirements specification
(End user responsibility because in charge of
implementing software-based diagnostics)
Code inspection results
(End user responsibility because in charge of
implementing software-based diagnostics)
Software module test specification
Software system integration test specification
Programmable electronic hardware and software
integration tests specification
(End user responsibility because in charge of
implementing software-based diagnostics)
