3.6.24

Ethernet (ETH): media access control (MAC) with DMA controller

SM CODE
Description
Ownership
Detailed implementation
Error reporting
Fault detection time
Addressed fault model
Dependency on MCU configuration
Initialization
Periodicity
Test for the diagnostic
Multiple faults protection
Recommendations and known limitations Refer to NVIC_SM_0
SM CODE
Description
Ownership
Detailed implementation
Error reporting
Fault detection time
Addressed fault model
Dependency on MCU configuration
Initialization
Periodicity
Test for the diagnostic
Multiple faults protection
Recommendations and known limitations -
SM CODE
Description
Ownership
UM1845 - Rev 4
Table 95. ETH_SM_0
ETH_SM_0
Periodical read-back of Ethernet configuration registers
End user
This method must be applied to Ethernet configuration registers (including those relate to unused
module features). Detailed information on the implementation of this method can be found in
Section 3.6.5
Refer to NVIC_SM_0
Refer to NVIC_SM_0
Refer to NVIC_SM_0
Refer to NVIC_SM_0
Refer to NVIC_SM_0
Refer to NVIC_SM_0
Refer to NVIC_SM_0
Refer to NVIC_SM_0
Table 96. ETH_SM_1
ETH_SM_1
Protocol error signals including hardware CRC
ST
Ethernet communication module embeds protocol error checks (like overrun, underrun, timeout,
packet composition violation etc.) and CRC-packet checks as well, conceived to detect network-
related abnormal conditions. These mechanisms are able anyway to detect a percentage of
hardware random failures affecting the module itself.
Error flag raise and optional Interrupt Event generation
Depends on peripheral configuration (e.g. baud rate), refer to functional documentation
Permanent and transient
None
Depends on implementation
Continuous
N/A
ETH_SM_2 information redundancy techniques on messages, including end-to-end safing
Table 97. ETH_SM_2
ETH_SM_2
Information redundancy techniques on messages, including End to End safing
End user
Description of hardware and software diagnostics
