3.6.12

Analog-to-digital converters (ADC)

SM CODE
Description
Ownership
Detailed implementation
Error reporting
Fault detection time
Addressed fault model
Dependency on MCU configuration
Initialization
Periodicity
Test for the diagnostic
Multiple faults protection
Recommendations and known limitations
SM CODE
Description
Ownership
Detailed implementation
Error reporting
Fault detection time
Addressed fault model
Dependency on MCU configuration
Initialization
Periodicity
Test for the diagnostic
Multiple faults protection
Recommendations and known limitations
SM CODE
Description
Ownership
UM1845 - Rev 4
Table 58.
ADC_SM_0
Periodical read-back of configuration registers
End user
This method must be applied to ADC configuration registers.
Detailed information on the implementation of this method can be found in
Refer to NVIC_SM_0
Refer to NVIC_SM_0
Refer to NVIC_SM_0
Refer to NVIC_SM_0
Refer to NVIC_SM_0
Refer to NVIC_SM_0
Refer to NVIC_SM_0
Refer to NVIC_SM_0
Refer to NVIC_SM_0
Table 59.
ADC_SM_1
Multiple acquisition by application software
End user
This method implements a timing information redundancy by executing multiple acquisitions on the
same input signal. Multiple acquisition data are then combined by a filter algorithm to determine the
signal correct value
Depends on implementation
Depends on implementation
Permanent and Transient
None
Depends on implementation
Continuous
Not needed
CPU_SM_0: periodical core self-test software
It is highly probable that this recommendation is satisfied by design by the end user application
software. Usage of multiple acquisitions followed by average operations is a common technique in
industrial applications where it is needed to survive with spurious EMI disturbs on sensor lines
Table 60.
ADC_SM_2
Range check by application software
End user
Description of hardware and software diagnostics
ADC_SM_0
ADC_SM_1
ADC_SM_2
UM1845
Section 3.6.5
page 44/108
