8 Appendix A – Communication Objects Table
OBJECT
TOPIC
NUMBER
On/Off 1 Control_ On/Off
2 Control_ Mode
3 Control_ Mode Cool/Heat
4 Control_ Mode Auto
5 Control_ Mode Heat
Mode 6 Control_ Mode Cool
7 Control_ Mode Fan
8 Control_ Mode Dry
Control_ Mode +/-
9
Control_ Mode +/-
Control_ Fan Speed / N Speeds
10
Control_ Fan Speed / N Speeds
11 Control_ Fan Speed Man/Auto
12 Control_ Fan Speed 1
Fan Speed
13 Control_ Fan Speed 2
14 Control_ Fan Speed 3
15 Control_ Fan Speed 4
16 Control_ Fan Speed 5
17 Control_ Fan Speed 6
© Intesis Software S.L.U. - All rights reserved
This information is subject to change without notice
®
IntesisBox is a registered trademark of Intesis Software SLU
NAME LENGTH
1 bit
1 byte DPT_HVACContrMode
1 bit DPT_Heat/Cool
1 bit
1 bit
1 bit
1 bit
1 bit
1 bit
1 bit DPT_UpDown
1 byte
1 byte DPT_Enumerated
1 bit
1 bit
1 bit
1 bit
1 bit
1 bit
1 bit
DATAPOINT TYPE FLAGS
DPT_NAME DPT_ID R W
DPT_Switch 1.001 W T
20.105 W T
1.100 W T
DPT_Bool 1.002 W T
DPT_Bool 1.002 W T
DPT_Bool 1.002 W T
DPT_Bool 1.002 W T
DPT_Bool 1.002 W T
DPT_Step 1.007 W
1.008 W
DPT_Scaling 5.001 W T
5.010 W T
DPT_Bool 1.002 W T
DPT_Bool 1.002 W T
DPT_Bool 1.002 W T
DPT_Bool 1.002 W T
DPT_Bool 1.002 W T
DPT_Bool 1.002 W T
DPT_Bool 1.002 W T
URL
Email
tel
User's manual r1.0 eng
FUNCTION
T U
0 - Off; 1-On
0 - Auto; 1 - Heat; 3 - Cool; 9 - Fan; 14 - Dry
0 - Cool; 1 - Heat
1 - Auto
1 - Heat
1 - Cool
1 - Fan
1 - Dry
0 - Decrease; 1 - Increase
0 - Up; 1 - Down
100*(n+0,5)/N %
1 - Speed1; 2 - Speed2; 3 - Speed3; 4 - Speed4;
5 - Speed5; 6 - Speed6; 7 - Speed7
0 - Manual; 1 - Auto
1 - Fan Speed 1
1 - Fan Speed 2
1 - Fan Speed 3
1 - Fan Speed 4
1 - Fan Speed 5
1 - Fan Speed 6
