- Page 1 ® IntesisBox BACnet/IP Server Modbus TCP Master User's manual Issue Date: 17/12/2012 r1 eng...
- Page 2 ® User’s Manual r1 eng IntesisBox BACnet/IP Server - Modbus TCP Master © Intesis Software S.L. All Rights Reserved. Information in this document is subject to change without notice. The software described in this document is furnished under a license agreement or nondisclosure agreement. The software may be used only in accordance with the terms of those agreements.
- Page 3 Gateway for the integration of Modbus TCP slave devices into BACnet/IP control systems. Models available for this gateway, with their following Order codes: IBOX-BAC-MBTCP-100 Tiny model with capacity of 110 internal datapoints. IBOX-BAC-MBTCP-A Basic model with capacity of 500 internal datapoints.
-
Page 4: Table Of Contents
Power device ....................11 Connect to Modbus TCP................12 Connect to BACnet ..................12 Connect to PC (LinkBoxBacnet) ..............12 LinkBoxBacnet. Configuration & monitoring of IntesisBox BACnet series ....14 Project configuration ..................14 5.1.1 Connection configuration ................ 14 5.1.2 Signals configuration ................ -
Page 5: Description
From now on, and with the aim of easy the read of this document, the words "gateway" or “IntesisBox” are used instead of IntesisBox BACnet/IP Server - Modbus TCP Master. Any other use of the word "gateway" not meaning IntesisBox BACnet/IP Server - Modbus TCP Master will be specifically indicated. -
Page 6: Functionality
1.2 Functionality The integration operation is as follow: From the Modbus TCP system point of view, after the start up process, IntesisBox reads continuously the points configured to be read in the Modbus TCP slave devices, and updates in its memory all the values received from the Modbus TCP system. -
Page 7: Capacity Of Intesisbox
Number of Modbus TCP Slave devices TCP Slave devices supported by the device There are different models of IntesisBox BACnet/IP Server - Modbus TCP Master, with different capacity every one of them. Tiny model with capacity of 110 internal data points. -
Page 8: Interfaces
IntesisBox acts as master in the Modbus TCP network, and the other Modbus devices connected to the network communicating with IntesisBox must be always slave devices. Up to 5 Modbus TCP slave devices can be defined in IntesisBox, to communicate with them. 8 / 27 ©... - Page 9 Also the data encoding used for 16 bits registers (big-endian or little-endian) can be configured in IntesisBox Modbus interface. This is the byte order for data encoding (MSB..LSB or LSB..MSB). This data encoding, although is specified as big-endian in Modbus protocol specification, it varies depending on manufacturer/type of slave.
-
Page 10: Quick Setup
3. Quick Setup 1. Install LinkBoxBacnet. Details in section 5 2. Install IntesisBox in the desired installation site (DIN rail mounting inside a metallic industrial cabinet connected to ground is recommended). 3. Power up and connect the communication cables. Details in section 4. -
Page 11: Connection
Figure 4.1 Device connection diagram Ensure proper space for all connectors when mounted. The items supplied by Intesis Software for this integration are: IntesisBox BACnet/IP Server - Modbus TCP Master hardware Console cable. Standard DB9F-DB9M cable 1.8 meter long. ... -
Page 12: Connect To Modbus Tcp
4.2 Connect to Modbus TCP Connect the communication cable coming from the network hub or switch to the ETH port (Figure 4.1) of IntesisBox. The cable to be used depends on where the IntesisBox is being connected: Connecting directly to a Modbus TCP device:... - Page 13 ® User’s Manual r1 eng IntesisBox BACnet/IP Server - Modbus TCP Master IntesisBox DB9 M RS-232 (Straight) DB9 F Table 4.1 Configuration serial cable pinout 13 / 27 © Intesis Software S.L. - All rights reserved http://www.intesis.com This information is subject to change without notice Email info@intesis.com...
-
Page 14: Linkboxbacnet. Configuration & Monitoring Of Intesisbox Bacnet Series
(if the Software is already installed) or it can be downloaded from the link that can be found in the installation sheet supplied with the IntesisBox. In this section only the specific project configuration for IntesisBox BACnet/IP Server - Modbus TCP Master is going to be explained. - Page 15 Gateway: Enter the Default Gateway address (router address) in case the gateway (IntesisBox) is in a different sub network than other BACnet devices (supplied by the network administrator). Leave blank if there is no need of router address. ...
- Page 16 Version: Select the gateway model used: tiny,basic or extended. You can check the gateway model in the identification given by the device when it connects to LinkBoxBacnet, it appears in the IntesisBox Communication Console window once connected to the gateway IntesisBox_Bacnet_Modbus TCP-100…...
-
Page 17: Signals Configuration
BACnet COV subscriptions 5.1.2 Signals configuration Select the Signals tab (Figure 5.5) to configure the signals list (the IntesisBox internal points). More information about the meaning of the columns can be found in the tables below. - Page 18 From 1 to 255 Edit mode Text edit or AutoEnumeration Modbus Code Description Modbus function code to be used by IntesisBox to read, to write or to read/write the point in the slave device. Values 0- Communication Error 1- Read digital outputs...
- Page 19 ® User’s Manual r1 eng IntesisBox BACnet/IP Server - Modbus TCP Master Format Description Modbus TCP data format for the point. Values 1. 1 bit. 2. 16 bits uns: 16 bits unsigned. 3. 16 bits sig: 16 bits signed. The MSbit represents the sign.
- Page 20 1 in Frac column. Then the value decoded by IntesisBox from the slave will be divided by 10, and the value will be multiplied by 10 before writing to the slave, thus will be the real value in the device (including integer and fractional part).
- Page 21 ® User’s Manual r1 eng IntesisBox BACnet/IP Server - Modbus TCP Master Bac.Name Description BACnet object name for the signal. This name is included into the BACnet's Object_name property for the point and it will be collected by any BACnet explorer.
- Page 22 ® User’s Manual r1 eng IntesisBox BACnet/IP Server - Modbus TCP Master Active Description Indicates if the signal is active or not for the integration Values 0: Not active 1: Active Edit mode Text edit or AutoEnumeration 0 / 1 based register...
-
Page 23: How To Configure Read/Write Points
Modbus TCP Code and select a BACnet Type Output or Value for the point (i.e. AO, AV, BO, BV, MO, MV). With this, IntesisBox will use function code 03 for read the point in every polling cycle, and whenever a new value for the point is received from BACnet, the new value will be written in the Modbus TCP slave device using function code 06. -
Page 24: Saving The Configuration
® User’s Manual r1 eng IntesisBox BACnet/IP Server - Modbus TCP Master 5.1.4 Saving the configuration When the configuration of the project is finished follow the next steps: 1. Click the button Save. Once accepted the pop-up message, that will save the project in the folder on hard disk (more information in LinkBoxBacnet Manual). - Page 25 BACnet/IP Server - Modbus TCP Master 5. Once in the configuration window again, click on exit. The configuration is ready to be sent to the IntesisBox (check LinkBoxBacnet Manual) The configuration cannot be received from the gateway to LinkBoxBacnet, it can only be sent.
-
Page 26: Mechanical & Electrical Characteristics
® User’s Manual r1 eng IntesisBox BACnet/IP Server - Modbus TCP Master 6. Mechanical & electrical characteristics Plastic, type PC (UL 94 V-0). Enclosure Dimensions: 107mm x 105mm x 58mm. Colour Light Grey. RAL 7035. 9 to 30Vdc +/-10%, Max.: 125mA. -
Page 27: Dimensions
® User’s Manual r1 eng IntesisBox BACnet/IP Server - Modbus TCP Master 7. Dimensions Power Ethernet port Console 58 mm port 107 mm 105 mm Free space recommended to install the device into a cabinet (wall or DIN rail mounting),...
