KNX – IR Universal AC
®
IntesisBox

Connection to KNX

IntesisBox device needs to be connected directly through a KNX TP-1 bus.
To get access to the KNX connector, remove the screw as seen in
Disconnect power of the KNX bus. Connect the IS-IR-KNX-1i to the KNX TP-1 (EIB) bus using the KNX standard
connector (red/grey) of the IS-IR-KNX-1i, respect polarity.
Reconnect power of the KNX bus, and mains power of the AC unit.
© Intesis Software S.L.U. - All rights reserved
This information is subject to change without notice
IntesisBox ® is a registered trademark of Intesis Software SLU
Setscrew
Figure 3.5 Top lid release and KNX connection
User's manual r1.0 eng
.
Figure 3.5
