If set to "no" the communication objects will not be shown.
o
If set to "yes" the communication objects will appear. To execute a scene by using these objects, a "1"
o
value has to be sent to the scene's object we want to execute (i.e. to execute scene 4, a "1" has to be sent
to the Control_ Execute Scene 4 object).

5.8.5 Scene "x" preset

This parameter lets you define a preset for a scene (the following description is valid for all the scenes).
If set to "no" the preset for the scene "x" will be disabled.
o
If set to "yes" the preset will be enabled. When a scene is executed the values configured in the preset will
o
be aplied.
Important: If a scene's preset is enabled, will not be possible to modify (store) the scene from the KNX
bus.
➢ Scene "x" / Value for On-Off
This parameter lets you choose the power of the indoor unit when the scene is executed. The following
options are available: "ON", "OFF" or "(unchanged)".
➢ Scene "x" / Value for Mode
This parameter lets you choose the mode of the indoor unit when the scene is executed. The following
options are available: "AUTO", "HEAT", "COOL", "FAN", "DRY", or "(unchanged)".
➢ Scene "x" / Value for Fan Speed
This parameter lets you choose the fan speed of the indoor unit when the scene is executed. The
following options are available: "SPEED 1", "SPEED 2"... "SPEED N", or "(unchanged)".
➢ Scene "x" / Value for Vane Up-Down
This parameter lets you choose the vane position of the indoor unit when the scene is executed. The
following options are available: "POSITION 1", "POSITION 2"... "POSITION N", "SWIRL", "SWING"
or "(unchanged)".
➢ Scene "x" / Value for Vane Left-Right
This parameter lets you choose the vane position of the indoor unit when the scene is executed. The
following options are available: "POSITION 1", "POSITION 2"... "POSITION N", "SWIRL", "SWING"
or "(unchanged)".
➢ Scene "x" / Value for Setp Temp (ºC)
This parameter lets you choose the setpoint temperature of the indoor unit when the scene is executed.
The following options are available: from "16ºC" to "32ºC" (both included), or "(unchanged)".
