IntesisBox IS-IR-KNX-1i User Manual page 44

– IR Universal AC
®
IntesisBox KNX
38 Control_ Vane Left-Right Pos2
39 Control_ Vane Left-Right Pos3
40 Control_ Vane Left-Right Pos4
41 Control_ Vane Left-Right Pos5
42 Control_ Vane Left-Right Pos6
43 Control_ Vane Left-Right Pos7
44 Control_ Vane Left-Right Pos8
45 Control_ Vane Left-Right Swing
46 Control_ Vane Left-Right Swirl
47 Control_ Vane Left-Right Wide
Control_ Vane Left-Right +/-
48
Control_ Vane Left-Right +/-
49 Control_ Vane Left-Right Move Pos
50 Control_ Setpoint Temperature
Control_ Setpoint Temp +/-
51
Temperature
Control_ Setpoint Temp +/-
52 Control_ Ambient Temperature
Window 53 Control_ Window Contact Input
Occupancy 54 Control_ Occupancy Input
Locking 55 Control_ Lock Remote Control
56 Control_ Operating Hour Counter
Operating Time
57 Control_ Operating Second Counter
58 Control_ Save/Exec Scene
Scenes 59 Control_ Store Scene1
60 Control_ Store Scene2
© Intesis Software S.L.U. - All rights reserved
This information is subject to change without notice
®
IntesisBox is a registered trademark of Intesis Software SLU
1 bit DPT_Bool 1.002
1 bit DPT_Bool 1.002
1 bit DPT_Bool 1.002
1 bit DPT_Bool 1.002
1 bit DPT_Bool 1.002
1 bit DPT_Bool 1.002
1 bit DPT_Bool 1.002
1 bit DPT_Bool 1.002
1 bit DPT_Bool 1.002
1 bit DPT_Bool 1.002
1 bit DPT_Step 1.007
1 bit DPT_UpDown 1.008
1 bit DPT_Trigger 1.002
2 byte DPT_Value_Temp 9.001
1 bit DPT_Step 1.007
1 bit DPT_UpDown 1.008
2 byte DPT_Value_Temp 9.001
1 bit DPT_Window_Door 1.019
1 bit DPT_Occupancy 1.018
1 bit DPT_Bool 1.002
2 byte DPT_Time (Hours) 7.007
2 byte DPT_Time_Lag (Sec) 13.100
1 byte DPT_SceneControl 18.001
1 bit DPT_Bool 1.002
1 bit DPT_Bool 1.002
User's manual r1.0 eng
W T 1 - Position 2
W T 1 - Position 3
W T 1 - Position 4
W T 1 - Position 5
W T 1 - Position 6
W T 1 - Position 7
W T 1 - Position 8
0 - Stop; 1 – Swing
W T
0 - Stop; 1 – Swirl
W T
0 - Stop; 1 – Wide
W T
0 - Decrease; 1 – Increase
W
0 - Up; 1 – Down
W
W T 0,1 Move Position
W T 16ºC to 32ºC
0 - Decrease; 1 – Increase
W
0 - Up; 1 – Down
W
W T ºC value
W T 0 - Closed; 1 - Open
0 – Not Occupied; 1 - Occupied
W T
0 - Unlocked; 1 – Locked
W T
W T Number of operating hours
W T Number of operating seconds
0 to 4 - Exec. Scene 1 to 5;
W
128 to 132 - Save Scene 1 to 5
W 1 - Store Scene
W 1 - Store Scene
