KNX – IR Universal AC
®
IntesisBox
3 Device Installation
Location selection
Determining that the IntesisBox device will be working as expected in the installation location is an important
stage. In order to determine the best location for your IntesisBox device, use the Wireless Controller (the one
of your AC unit).
When selecting the installation location, please keep in mind that the IntesisBox device has 2 IR emitters and 1
IR receiver. The 2 emitters increase the installation possibilities allowing many different suitable positions for
the device location. On the other hand, the receiver offers the possibility to get the feedback from the IR wireless
remote controller so the KNX status objects can be updated with that feedback.
IR transmission area
© Intesis Software S.L.U. - All rights reserved
This information is subject to change without notice
IntesisBox
®
is a registered trademark of Intesis Software SLU
Figure 3.1 IR emitters and IR receiver location
User's manual r1.0 eng
IR reception area
URL
http://www.intesisbox.com
Email
info@intesisbox.com
tel
+34 938047134
8 / 48
