IntesisBox IS-IR-KNX-1i User Manual page 47

– IR Universal AC
®
IntesisBox KNX
101 Status_ Vane Up-Down Swirl
102 Status_ Vane Up-Down Wide
103 Status_ Vane Up-Down Text
Status_ Vane Left-Right / 8 pos
104
Status_ Vane Left-Right / 8 pos
105 Status_ Vane Left-Right Man/Auto
106 Status_ Vane Left-Right Pos1
107 Status_ Vane Left-Right Pos2
108 Status_ Vane Left-Right Pos3
109 Status_ Vane Left-Right Pos4
110 Status_ Vane Left-Right Pos5
111 Status_ Vane Left-Right Pos6
112 Status_ Vane Left-Right Pos7
113 Status_ Vane Left-Right Pos8
114 Status_ Vane Left-Right Swing
115 Status_ Vane Left-Right Swirl
116 Status_ Vane Left-Right Wide
117 Status_ Vane Left-Right Text
118 Status_ AC Setpoint Temp
Temperature 119 Status_ IntesisBox Ambient Temp
120 Status_ IntesisBox Reference Temp
121 Status_ Error/Alarm
Error 122 Status_ Error Code
123 Status_ Error Text code
© Intesis Software S.L.U. - All rights reserved
This information is subject to change without notice
IntesisBox ® is a registered trademark of Intesis Software SLU
1 bit DPT_Bool 1.002
1 bit DPT_Bool 1.002
14 byte DPT_String_8859_1 16.001
1 byte DPT_Scaling 5.001
1 byte DPT_Enumerated 5.010
1 bit DPT_Bool 1.002
1 bit DPT_Bool 1.002
1 bit DPT_Bool 1.002
1 bit DPT_Bool 1.002
1 bit DPT_Bool 1.002
1 bit DPT_Bool 1.002
1 bit DPT_Bool 1.002
1 bit DPT_Bool 1.002
1 bit DPT_Bool 1.002
1 bit DPT_Bool 1.002
1 bit DPT_Bool 1.002
1 bit DPT_Bool 1.002
14 byte DPT_String_8859_1 16.001
2 byte DPT_Value_Temp 9.001
2 byte DPT_Value_Temp 9.001
2 byte DPT_Value_Temp 9.001
1 bit DTP_Alarm 1.005
2 byte Enumerated
14 byte DPT_String_8859_1 16.001
User's manual r1.0 eng
R T 0 - Stop; 1 - Swirl
R T 0 - Stop; 1 - Wide
R T ASCII String
R T 100*(n+0,5)/N %
1 - Pos1; 2 - Pos2; 3 - Pos3; 4 - Pos4; 5 - Pos5;
R T
6 - Pos6; 7 - Pos7; 8 - Pos8
R T 0 - Manual; 1 - Auto
R T 1 - Position 1
R T 1 - Position 2
R T 1 - Position 3
R T 1 - Position 4
R T 1 - Position 5
R T 1 - Position 6
R T 1 - Position 7
R T 1 - Position 8
R T 0 - Stop; 1 - Swing
R T 0 - Stop; 1 - Swirl
R T 0 - Stop; 1 - Wide
R T ASCII String
R T 16ºC to 32ºC
R T ºC value
R T ºC value
R T 0 - No Alarm; 1 - Alarm
R T 0 - No Error; Any other see user's manual
R T 2 char Error; Empty - none
