5 ETS Parameters and Configuration

The IntesisBox IS-IR-KNX-1i interface is configured through ETS. General KNX parameters, such as the
physical address, group addresses or DPTs can be configured as usual using the ETS interface. For the specific
AC unit configuration and IR communication, the use of the specific plugin included in the ETS database is
required.
ETS database for this device can be downloaded from:
https://www.intesisbox.com/intesis/product/media/IS-IR-KNX-1i_ETS_database.zip
Please consult the README.txt file, located inside the downloaded zip file, to find instructions on how to install
the database.
Once the database is imported, the plugin can be accessed when editing parameters. To get access to
parameters edition, click on the Parameter tab, located in the project screen, and then press the specific
parameter dialog.
Remember that before start using the IntesisBox interface along with the AC unit, you need to set up at least
the brand and type of you AC unit. Check section 5.1 for more information about it.
IMPORTANT: Please, update the Catalogue before proceeding with the device configuration and programming.
The laptop where ETS is running shall have Internet connection to update the catalogue.
© Intesis Software S.L.U. - All rights reserved
This information is subject to change without notice
®
IntesisBox is a registered trademark of Intesis Software SLU
Figure 5.1 ETS Project managing and plugin screen
