IntesisBox IS-IR-KNX-1i User Manual page 46

– IR Universal AC
®
IntesisBox KNX
79 Status_ Mode Text
Status_ Fan Speed / N Speeds
80
Status_ Fan Speed / N Speeds
81 Status_ Fan Speed Man/Auto
82 Status_ Fan Speed 1
83 Status_ Fan Speed 2
Fan Speed
84 Status_ Fan Speed 3
85 Status_ Fan Speed 4
86 Status_ Fan Speed 5
87 Status_ Fan Speed 6
88 Status_ Fan Speed 7
89 Status_ Fan Speed Text
Status_ Vane Up-Down / 8 pos
90
Status_ Vane Up-Down / 8 pos
91 Status_ Vane Man/Auto
92 Status_ Vane Up-Down Pos1
93 Status_ Vane Up-Down Pos2
94 Status_ Vane Up-Down Pos3
Vanes
95 Status_ Vane Up-Down Pos4
96 Status_ Vane Up-Down Pos5
97 Status_ Vane Up-Down Pos6
98 Status_ Vane Up-Down Pos7
99 Status_ Vane Up-Down Pos8
100 Status_ Vane Up-Down Swing
© Intesis Software S.L.U. - All rights reserved
This information is subject to change without notice
®
IntesisBox is a registered trademark of Intesis Software SLU
14 byte DPT_String_8859_1 16.001
1 byte DPT_Scaling
1 byte DPT_Enumerated
1 bit DPT_Bool
1 bit DPT_Bool
1 bit DPT_Bool
1 bit DPT_Bool
1 bit DPT_Bool
1 bit DPT_Bool
1 bit DPT_Bool
1 bit DPT_Bool
14 byte DPT_String_8859_1 16.001
1 byte DPT_Scaling
1 byte DPT_Enumerated
1 bit DPT_Bool
1 bit DPT_Bool
1 bit DPT_Bool
1 bit DPT_Bool
1 bit DPT_Bool
1 bit DPT_Bool
1 bit DPT_Bool
1 bit DPT_Bool
1 bit DPT_Bool
1 bit DPT_Bool
R T ASCII String
5.001 R T 100*(n+0,5)/N %
1 - Speed1; 2 - Speed2; 3 - Speed3; 4 - Speed4;
5.010 R T
5 - Speed5; 6 - Speed6; 7 - Speed7
1.002 R T 0 - Manual; 1 - Auto
1.002 R T 1 - Speed 1
1.002 R T 1 - Speed 2
1.002 R T 1 - Speed 3
1.002 R T 1 - Speed 4
1.002 R T 1 - Speed 5
1.002 R T 1 - Speed 6
1.002 R T 1 - Speed 7
R T ASCII String
5.001 R T 100*(n+0,5)/N %
1 - Pos1; 2 - Pos2; 3 - Pos3; 4 - Pos4; 5 - Pos5;
5.010 R T
6 - Pos6; 7 - Pos7; 8 - Pos8
1.002 R T 0 - Manual; 1 - Auto
1.002 R T 1 - Position 1
1.002 R T 1 - Position 2
1.002 R T 1 - Position 3
1.002 R T 1 - Position 4
1.002 R T 1 - Position 5
1.002 R T 1 - Position 6
1.002 R T 1 - Position 7
1.002 R T 1 - Position 8
1.002 R T 0 - Stop; 1 - Swing
