Select a memory page:
Press and hold the [MEMS] button, then press the bump button (1-12) corresponding to the
page you want to load. Pressing MEMS twice in rapid succession will automatically select
page 1.
The current page is indicated by a bump button lit solid red. The current page number
is also indicated in the LCD window while the [MEMS] button is pressed.
If a bump button's LED is off, the corresponding page contains no recorded memories.
If a bump button's LED is blinking red, there are some memories recorded on that page.
Record a memory:
Step 1:
N o t e :
When recording memories, ensure that the [NEXT] button is not illuminated. If you record
memories while in next mode, your levels may not be recorded accurately to the memory.
Step 2:
Step 3:
Step 4:
Use [CLEAR] to cancel recording:
Press [CLEAR] to cancel recording. The console reverts back to whatever fader mode it
was in before the [REC MEM] button was pressed.
Use [UNDO] to revert to the previously recorded memory:
If you record a memory to the incorrect location, press [UNDO] immediately. The incorrect
memory will be erased and the previous levels will be restored.
2
Normal Mode
Set channel levels using faders 1-24 (or 1-48). Use the channel range buttons,
[1-24] and [25-48] (or [1-48] and [49-96]), to access channels as needed. You
may also record existing memories into new memories.
Press [REC MEM]. The [REC MEM] button lights and the console switches to
memory mode. The LCD shows the current page number, and bump buttons
beneath the faders light as follows:
Off . . . . . . . . . . . . . Unavailable to record. This will only appear on memory
Blink full red . . . . . . Empty memory.
Blink dim red . . . . . Occupied memory. If you record to this location, the old
If needed, press and hold the [MEMS] button, then press the bump button (1-12)
corresponding to the page you want to load.
Press a bump button. The memory is recorded, the [REC MEM] button goes out
and the console reverts back to whatever fader mode it was in before the [REC
MEM] button was pressed.
01/01 if it has been set to master DMX Input.
levels will be overwritten.
19
