Switch Settings
This section describes the function of the DIP switches
. The locations and default settings of the switches are shown in
SW10
Figure
2-2.
Figure 2-2. Switch Locations
Audio Amplification Selection (SW1)
The
switch determines the amplification of right and left signals con-
SW1
nected to the
LINE IN
can be used by simply varying the switch setting to the values shown in
Table
2-2. An amplification gain of a factor of 10 can be achieved by set-
ting the switch into electret microphone use.
ADSP-TS201S EZ-KIT Lite Evaluation System Manual
ADSP-TS201S EZ-KIT Lite Hardware Reference
connector
. A non-powered electret microphone
J9
,
, and
SW1
SW2
2-5
