Ref.
Qty.
Description
27
7
MOMENTARY
SWT013
28
3
.05 45X2 CON019
29
2
DIP6 SWT017
30
4
RJ45 8PIN
CON_RJ45
31
1
DIP4 SWT018
32
1
IDC 6X1 IDC6X1
33
1
IDC 7X2 IDC7X2
34
2
3.5MM
STEREO_JACK
CON001
35
1
IDC 13x2 IDC13x2
36
1
5A RESETABLE
FUS005
37
15
0 1/4W 5% 1206
38
4
YELLOW LED001
39
1
22PF 50V 5% 0805
40
2
330PF 50V 5%
0805
41
4
0.01UF 100V 10%
0805
42
10
0.1UF 50V 10%
0805
ADSP-TS201S EZ-KIT Lite Evaluation System Manual
ADSP-TS201 EZ-KIT Lite Bill Of Materials
Reference
Manufacturer
Designator
SW3-9
PANASONIC
J1-3
SAMTEC
SW2,SW10
CTS
J4-7
TYCO
SW1
ITT
P5
FCI
ZP4
FCI
J9-10
A/D ELEC-
TRONICS
P6
BERG
F1
MOUSER
R76,R91,R104,
KOA
R107,R109-110,
R113,R118,
R161-164,
R178-179,R202
LED3-6
PANASONIC
C63
AVX
C25,C30
AVX
C1-2,C7-8
AVX
C4,C142-143,
AVX
C145-149,
C153,C249
Part Number
EVQ-PAD04M
SFC-145-T2-F-D-A
218-6LPST
1-16609214-1
TDA04HOSB1
90726-406HLF
68737-414HLF
ST-323-5
54102-T08-13LF
650-RGEF500
0.0ECTRk7372BTTED
LN1461C
08055A220JAT
08055A331JAT
08051C103KAT2A
08055C104KAT
A-3
