Audio (J9 and J10)

There are two 3.5 mm stereo audio jacks.
Part Description
3.5 mm stereo jack
3.5 mm stereo plug to 3.5 mm
stereo cable

Power (J8)

The power connector provides all the power necessary to operate the
EZ-KIT Lite board.
Part Description
2.5 mm power jack
7.5V power supply

JTAG (ZP4)

The JTAG header is the connecting point for a JTAG in-circuit emulator
pod. For more information about a JTAG custom board design or inter-
face, please refer to EE-68 found at Analog Devices Web site.
Pin 3 is missing to provide keying. Pin 3 in the mating connector
should have a plug. When an emulator is connected to the JTAG
header, the USB debug interface is disabled.
When using an emulator with the EZ-KIT Lite board, follow the
connection instructions provided with the emulator.
ADSP-TS201S EZ-KIT Lite Evaluation System Manual
ADSP-TS201S EZ-KIT Lite Hardware Reference
Manufacturer
A/D ELECTRONICS
Mating Connector
RADIO SHACK
Manufacturer
SWITCHCRAFT
DIGI-KEY
Mating Power Supply (shipped with the EZ-KIT Lite)
CUI
Part Number
ST-323-5
L12-2397A
Part Number
RAPC712X
RAPC712X-ND
DTS075400UDC-P6P-DB
2-21
