Analog Devices ADSP-TS201S EZ-KIT Lite Manual page 87

A
VDD (1.0V) Bypass Caps (per DSP)
(8) 1nF C173 C174
1 (4) 0.01uF 1000PF 1000PF
(5) 0.1uF 0402 0402
(1) 100uF
ALL BYPASS CAPS SHOULD BE PLACED AS CLOSE AS POSSIBLE TO THE CORISPONDING IC
TRACES FROM COMPONENT TO CAPACITOR AND FROM THE CAPACITOR TO GND SHOULD BE AS SHORT AS POSSIBLE
THE PRIORITY FOR THE PLACEMENT:
1V_DSP_X
1_5V_DSP_X
2_5V_DSP_X
2
VDD_DRAM (1.5V) Bypass Caps (per DSP)
(6) 1nF C67
(2) 0.01uF 1000PF
(4) 0.1uF 0402
(1) 100uF
3
VDD_IO (2.5V) Bypass Caps (per DSP)
(8) 1nF
(2) 0.01uF C194 C193
(4) 0.1uF 1000PF 1000PF
(1) 100uF 0402 0402
4
A
B
1V_DSP_A
C175 C176 C177 C178 C179 C180 C219
1000PF 1000PF 1000PF 1000PF 1000PF 1000PF 0.01UF
0402 0402 0402 0402 0402 0402 0402
1_5V_DSP_A
C168 C169 C170 C171 C172 C68 C167
1000PF 1000PF 1000PF 1000PF 1000PF 0.01UF 0.01UF
0402 0402 0402 0402 0402 0402 0402
2_5V_DSP_A
C192 C191 C190 C189 C188 C186 C181
1000PF 1000PF 1000PF 1000PF 1000PF 1000PF 0.01UF
0402 0402 0402 0402 0402 0402 0402
B
C218 C216 C220 C221 C222 C223 C224
0.01UF 0.01UF 0.01UF 0.1UF 0.1UF 0.1UF 0.1UF
0402 0402 0402 0402 0402 0402 0402
C206 C196 C207 C208
1000PF 1000PF 1000PF 1000PF
0402 0402 0402 0402
C165 C166 C75 C69
0.1UF 0.1UF 0.1UF 0.1UF
0402 0402 0402 0402
C183 C182 C187 C185 C184
0.01UF 0.1UF 0.1UF 0.1UF 0.1UF
0402 0402 0402 0402 0402
C
C225
0.1UF
0402
1V_DSP_B
C209 C210 C195 C211 C203 C204 C205
1000PF 1000PF 1000PF 1000PF 0.01UF 0.01UF 0.01UF
0402 0402 0402 0402 0402 0402 0402
1_5V_DSP_B
C212 C226 C217 C215 C214 C213
1000PF 1000PF 1000PF 1000PF 1000PF 1000PF
0402 0402 0402 0402 0402 0402
2_5V_DSP_B
C234 C246 C236 C245 C233 C244 C243
1000PF 1000PF 1000PF 1000PF 1000PF 1000PF 1000PF
0402 0402 0402 0402 0402 0402 0402
ANALOG
DEVICES
Title
Size Board No.
C
Date 1-10-2007_10:57
C
D
C202 C201 C200 C199 C198 C197
0.01UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF
0402 0402 0402 0402 0402 0402
C232 C227 C229 C228 C230 C231
0.01UF 0.01UF 0.1UF 0.1UF 0.1UF 0.1UF
0402 0402 0402 0402 0402 0402
C235 C242 C240 C241 C237 C238 C239
1000PF 0.01UF 0.01UF 0.1UF 0.1UF 0.1UF 0.1UF
0402 0402 0402 0402 0402 0402 0402
20 Cotton Road
Nashua, NH 03063
PH: 1-800-ANALOGD
ADSP-TS201S EZ-KIT LITE
DSP BYPASS CAPS
Rev
A0178-2002
2.1C
Sheet 15 of 15
