Connectors
USB (ZJ1)
The USB connector is a standard type B USB receptacle.
Part Description
Type B USB receptacle
USB cable (provided with the kit)
Expansion Interface (J1–3)
Three board-to-board connectors provide signals for most of the proces-
sor's peripheral interfaces. The connectors are located at the bottom of the
board. For more information about the expansion interface, see
sion Interface" on page
Part Description
90-position 0.05" spacing
90-position 0.05" spacing
(through hole)
90-position 0.05" spacing
(surface mount)
90-position 0.05" spacing
(low cost)
2-22
Manufacturer
MILL-MAX
DIGI-KEY
Mating Connector
ASSMAN
RANDOM
2-3.
Manufacturer
SAMTEC
Mating Connectors
SAMTEC
SAMTEC
SAMTEC
ADSP-TS201S EZ-KIT Lite Evaluation System Manual
Part Number
897-43-004-90-000000
ED90064-ND
AK672/2-3
USB-AB-1004A
"Expan-
Part Number
SFC-145-T2-F-D-A
TFM-145-x1 series
TFM-145-x2 series
TFC-145 series
