For the supplied memory, the
follows:
• SDRAM enable, CAS latency of two cycles
• Pipe depth of zero, page boundary of 256 words
• Refresh rate of every 3700 cycles, precharge to RAS of two cycles
• RAS to precharge of five cycles
• Init sequence is MRS cycle follows refresh
The
SYSCON
They can be written only once after reset and cannot be changed
during system operation.
In emulation space, the
written to as many times as needed. The USB debug monitor oper-
ates in emulation space and allows "always writable" mode for these
registers.

Flash Memory

The AT49BV040 chip provides a total of 512K x 8-bits of external flash
memory, arranged into eight uniform 64 Kb memory blocks. The block
addresses are shown in
Table 1-2. Flash Memory Map
Start Address
0x3000 0000
0x3001 0000
0x3002 0000
0x3003 0000
ADSP-TS201S EZ-KIT Lite Evaluation System Manual
SDRCON
and registers define bus control configuration.
SDRCON
SYSCON
Table 1-2.
End Address
0x3000 FFFF
0x3001 FFFF
0x3002 FFFF
0x3003 FFFF
Using ADSP-TS201S EZ-KIT Lite
register should be configured as
and the registers can be
SDRCON
Content
Uniform block 0
Uniform block 1
Uniform block 2
Uniform block 3
1-9
