VIEW PRESET Keys
The VIEW PRESET keys are used to save your three favorite views for quick
retrieval. Instead of using the VIEW key to cycle through all the views to find the
one you want, you can program the VIEW PRESET keys to display a specific view
immediately. See Views for more information.
EXIT Key
The EXIT key has multiple functions, which depend on the situation.
• If an alarm is sounding, press the EXIT key to cancel the alarm.
• If a menu tab is selected, press the EXIT key to exit the menu mode and return to the
view.
• If a menu is active, press the EXIT key to return to the previous level in the menu
system.
• From any view, press the EXIT key to cycle through the available views in reverse order.
• If Freeze Frame is active, press the EXIT key to return to a scrolling display.
• If the Cursor is active, press the EXIT key to remove the cursor from the display.
INFO Key
The INFO key has multiple functions, which depend on the active view and
situation.
Chart Views: Press the INFO key while in any navigation view to display information about
objects that are near the active cursor. If the cursor is not active, the Chart Info submenu will
be displayed. See Views: Viewing Cartography for more information.
Screen Snapshots: In Chart views, highlight a screen snapshot or recording icon and press the
Info key. Select Chart Info or View Snapshot from the submenu. See Snapshot and Recording
View for more information.
Key Functions
54
