Chart/Chart Combo View
Chart/Chart Combo View shows two versions of the Chart view in a combination split screen
so that you can see the position of the boat on one side while you zoom in or perform other
functions on the other. See Chart View for more information.
13
1
2
1
Next Waypoint
2
Depth
3
XTE (Cross Track Error): Distance of Boat from Route
4
Speed: the measurement of the boat's progress across a given
distance, and is the speed measurement provided by GPS
5
Course: the current direction the boat is traveling measured
in degrees from North
6
Bearing: Direction to Destination Waypoint
measured in degrees from North
Combo Views
Chart/Chart Combo View (Navigating)
11
1
10
9
8
7
3
4
12
13
5
104
11
10
1
9
8
7
6
Cartography
Off Course Limits
Track
Boat Icon
Course Projection Line
Route
Map Scale
7
8
9
10
11
12
13
14
