Active Side allows you to select a side of the screen in Combo View. After you choose an active
side, you can apply menu settings and key commands to the view you've selected. The Active
Side menu option is only available when a Combo View is on the screen (see Views: Combo
Views).
• A green arrow on the Combo View points to the active side.
• When a menu is displayed in the active side, the non-active side of the screen will be
grayed out.
Split Position sets the size of the left side of the Combo View. Each Combo View can be set
individually. The Split Position menu option is only available when a Combo View is on the
screen (see Views: Combo Views).
• The number setting indicates the percentage taken up by the left side of the Combo
View.
• Selecting Left sets the left side of the screen to its smallest setting.
Waypoint [Name] allows you to view the Waypoints submenu for the waypoint under your
cursor. You can move the cursor onto an existing waypoint and press the MENU key once, or use
Cursor to Waypoint to select a waypoint from the saved waypoints list.
NOTE: See Introduction to Navigation for more Waypoints information.
The Waypoint Submenu contains the following menu options:
Edit allows you to edit the Name, Position (Latitude and Longitude), and select the Icon
that will be used to represent the waypoint in the Chart and Combo Views.
Delete allows you to delete a waypoint from the saved waypoints list.
Target allows you to apply a target to a waypoint selected from the saved waypoints list.
Grid allows you to apply a trolling grid to a waypoint selected from the saved waypoints
list.
Navigation X-Press™ Menu
Active Side
(Combo Views only)
Settings: Left, Right, Default = Left
Split Position
(Combo Views only)
Settings: Left, 30, 40, 50, 60, 70, Right; Default = Various
Waypoint [Name]
(Only with an active cursor on a waypoint)
Settings: Edit, Delete, Target, Grid
150
