Bird's Eye View

Bird's Eye View shows a 3D perspective view of the track and the chart's land contour from a
point above and behind the boat (the eye point). As the boat turns, the eye point moves to follow
the boat.
• To shift the eye point position so that you can look off to the sides, or even behind the
boat: Press the RIGHT or LEFT Cursor keys to turn the eye point right or left. Press the
UP Cursor key to move the eye point forward, and press the DOWN Cursor key to move
the eye point backward.
• Press the EXIT key to move the eye point back to its original position behind and above
the boat.
• Digital Readouts: If all selectable readout boxes are turned off below the Bird's Eye
pane, the window will stretch to fill the whole vertical pane. See Setup Menu Tab:
Select Readouts for more information.
1
1 Depth
2 Temp: water surface temperature
3
Speed: speed of boat
4
Course: the current direction the boat is traveling measured in degrees from North
Bird's Eye View (Standard)
7
2
3
97
6
4 5
VLT: Voltage
5
Boat Icon
6
Cartography
7
Views
