Side Beam View
(optional-purchase QuadraBeam PLUS™ transducer required)
Side Beam View displays sonar data from the left and right 455 kHz beams and the 200 kHz
down-looking beam in one view. This view is available if an optional-purchase QuadraBeam
PLUS™ transducer accessory is connected and Transducer Select is set to QuadraBeam (see
Sonar Menu Tab: Transducer Select).
NOTE: The QuadraBeam PLUS™ transducer requires a separate purchase.
• Coverage: The sonar information from the side-looking beams reveals bottom contour,
structure, and fish similar to the down-looking beam, but the area covered is to the left
and right, which gives you a wider view of the bottom.
• Range: The distance covered by the right and left side-looking beams is controlled by
the Lower Range setting for the down-looking beam, up to a maximum of 160 feet (see
Sonar X-Press™ Menu: Lower Range).
• Layout: The Side Beam View can be arranged in any of the following layouts: Default,
Classic, and Slanted. Press the MENU key once, and select Quad Layout from the
X-Press™ Menu to choose a layout for this view.
93
