Chart/Side Imaging® Combo View
Chart/Side Imaging® Combo View shows chart information and Side Imaging® sonar
information in a combination split screen, where the Side Imaging® View is displayed on the left
and the Chart View is displayed on the right. For more information about each side of this combo
view, see Chart View and Side Imaging® View.
13
12
1
1
Depth
2
Temp: water surface temperature
3
Speed: speed of boat
4
Course: the current direction the boat is traveling measured in degrees from North
5
VLT: Voltage
6
Chart Window
7
Cartography
Combo Views
Chart/Side Combo View
8
11
2
(1198c SI only)
10
3
4
106
9
8
7
5
Boat Icon
Course Projection Line
Map Scale
Side View Range
Side View Window
Bottom Return
6
8
9
10
11
12
13
