Specifications

Depth Capability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1500 ft (500 m)
Power Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .500 Watts (RMS); 4000 Watts (Peak-To-Peak)
Operating Frequency
DualBeam PLUS™: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200 kHz and 83 kHz
Side Imaging® (1198c SI Combo models only): . . . . . . . . . . . . . . . . . . . . . . . . . . . . 455 kHz/800 kHz
Area of Coverage
DualBeam PLUS™: . . . . . . . . . . . . . . . . . . . 60° @ -10 dB in 83 kHz and 20° @ -10 dB in 200 kHz
Side Imaging® (1198c SI Combo models only): . . .455 kHz: (2) 86° @ -10 db (180° Total Coverage)
Target Separation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 1/2 Inches (63.5 mm)
Power Requirement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-20 VDC
LCD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .600 V x 800 H; 10.4" Diagonal Color TFT
Current Draw . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.4 A
Transducer
1198c SI Combo: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .XHS 9 HDSI 180 T
1158c DualBeam Combo: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .XNT 9 20 T
Transducer Cable Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 ft (6 m)
IPX Rating . . . . . . . . . . . . . . . . IP67 Waterproof/Submersible @ 1m for 30 minutes and dust tight
NOTE: Product specifications and features are subject to change without notice.
NOTE: Humminbird® verifies maximum stated depth in saltwater conditions, however actual depth
performance may vary due to transducer installation, water type, thermal layers, bottom composition and
slope.
ENVIRONMENTAL COMPLIANCE STATEMENT: It is the intention of Humminbird® to be a responsible
corporate citizen, operating in compliance with known and applicable environmental regulations, and a
good neighbor in the communities where we make or sell our products.
WEEE DIRECTIVE: EU Directive 2002/96/EC "Waste of Electrical and Electronic Equipment Directive
(WEEE)" impacts most distributors, sellers, and manufacturers of consumer electronics in the European
Union. The WEEE Directive requires the producer of consumer electronics to take responsibility for the
management of waste from their products to achieve environmentally responsible disposal during the
product life cycle.
WEEE compliance may not be required in your location for electrical & electronic equipment (EEE), nor may
it be required for EEE designed and intended as fixed or temporary installation in transportation vehicles
such as automobiles, aircraft, and boats. In some European Union member states, these vehicles are
considered outside of the scope of the Directive, and EEE for those applications can be considered
excluded from the WEEE Directive requirement.
800 kHz: (2) 55° @ -10 db (130° Total Coverage)
211
