Chart Speed determines the speed at which the sonar information moves across the display,
and consequently the amount of detail shown.
A faster speed shows more information and is preferred by most anglers; however, the sonar
information moves across the display quickly. A slower speed keeps the information on the
display longer, but the bottom and fish details become compressed and may be difficult to
interpret.
SI Colors allows you to select which color palette you would like to use for the Side Imaging®
and Down Imaging™ display.
Down Imaging Beam Width controls the width of the beam (side to side) for the
Down Imaging™ View and sets the amount of information shown on the display.
To see only the data directly under your boat, select Narrow. Medium reveals more information,
while Wide displays the maximum information available from the Down Imaging™ beam width.
Cancel Navigation discards the current route and exits Navigation Mode. This menu option will
only appear when you are currently navigating a route. This will not delete a previously-saved
route.
Down Imaging™ X-Press™ Menu

Chart Speed

Settings: 1-10, where 1 = Slow, 10 = Fastest; Default = 5

SI Colors

Settings: Blue, Amber1, Amber2, Brown, Green, Inverse, Gray,
Green/Red; Default = Blue
Down Imaging Beam Width
(Advanced, Down Imaging™ View only)
Settings: Narrow, Medium, Wide; Default = Wide
Cancel Navigation
(only when Navigating)
Settings: Press the RIGHT Cursor key and follow screen instructions.
