3.4 Chassis Components

Hard Drives

The SC946L JBOD chassis supports forty five 3.5" hard drives. They can be removed without
powering down the system if your operating system supports RAID. In addition, it supports
two 2.5" drives accessible at the rear of the chassis.

Hard Drive Carrier Indicators

Each hard drive carrier has two LED indicators: an activity indicator and a status indicator.
The status indicator functions in RAID configurations. For non-RAID configurations, it remains
off. See the table below for details.
Color
Activity
Blue
LED
Blue
Status
Red
LED
Red
Red
Red
Red
Note: Enterprise level hard disk drives are recommended for use in Supermicro chassis and
servers. For information on recommended HDDs, visit the Supermicro website and check the
"Drive Options" in the product webpage.
Chapter 3: Maintenance and Component Installation
Hard Drive Carrier LED Indicators
Blinking Pattern Behavior for Device
Solid On SAS drive installed
Blinking I/O activity
Solid On Failure of drive with RSTe support
Blinking at 1 Hz Rebuild drive with RSTe support
Blinking with two blinks Hot spare for drive with RSTe support
and one stop at 1 Hz
On for five seconds, Power on for drive with RSTe support
then off
Blinking at 4 Hz Identify drive with RSTe support
