SC946L JBOD User's Manual
D.6 IPMI Static IP to DHCP Setting
IP Address to DHCP Setting
1. Download the utility from the Supermicro website or technical support.
2. Extract the file to a known folder.
3. By default, the JBOD control board will be configured in static IP 192.168.1.99.
4. Change the host to static IP as 192.168.1.10.
5. Go to the IPMI website and select the Configuration tab and then select the Network page.
6. Change the setting from Static to DHCP mode
If default website is not responding, press the reset button for more than ten seconds to
reset to default. You will observe that the fan speed will slow and then return to normal.
Continue to change to DHCP mode when the fan reaches normal speed.
7. Save the new setting.
8. Change the host IP back to DHCP mode.
9. Determine the DHCP IP address of the host, for example 10.1.1.50.
10. Run the command prompt with administrative privileges.
11. Go to the utility folder and type:
findit 00-25-90-xx-xx-xx yy.zz.255.255
Where: xx-xx-xx is, enter the JBOD control board MAC ID. yy.zz represents the first two
octets of your host IP. Example: findit 00-25-90-xx-xx-xx 10.1.255.255
12. The utility will return the IP address of the JBOD control board. Enter the IP in browser
and access the IPMI web GUI.
