Chassis Rear

The illustration below shows the features included on the rear of the chassis. Power supply
modules display status lights.
2
Item Feature
1 Power Supply modules
2 Fans
3 Mini-SAS Ports
4 IPMI Port
1
2
Figure 1-3. Rear View
Rear Chassis Features
Description
Two, redundant hot-swap
Five, hot-swap
Mini-SAS HD ports for internal or external cascading expander combinations
SC946LE1C-R1K66JBOD
One for
Networking port used for remote management
11
