Chapter 3: Maintenance and Component Installation
Cascading Storage
The following diagram shows a server with a single host bus adapter (HBA). The SC946L JBOD
storage enclosure model E1C can accomodate this configuration.
HBA
Server with Single
Host Bus Adapter (HBA)
External Mini-SAS HD Cable
SC946LE1C-R1K66JBOD
SC946LE1C-R1K66JBOD
Figure 3-2. Sample Cascading Storage, Single HBA
37
