C.3 Components and LEDs
Component Side Connectors
J31
1
6
J16
J1
Figure C-1. BPN-SAS3-946LEL1 Connector Side Components
1. HDD Connectors: J31 - J45.
2. HDD Connectors: J16 - J30.
3. HDD Connectors: J1 - J15.
4. 12V Power Cable Input: NI_TP1 and
NI_TP2.
5. Ground Cable Input: NI_TP3 and NI_
TP4.
1
1
1
2
1
3
6. SDB and UART Connector for the
Secondary Expander: J53 and J54.
7. SDB and UART Connector for the
Primary Expander: J50 and J51.
71
Appendix C: Backplanes
J45
1
4
J30
1
7
1
5
J15
