3. Slide CMA connector #3 forward onto the two posts on the rear of the left middle rail. It
snaps into place.
4. For CMA connector #4, align the metal tabs with the slots on the rear of the left outer
rail and push it forward. It snaps into place.
Figure 2-9. Intalling the Connectors 3 and 4
Chapter 2 Installation in a Rack
4
4
3
3
31
