Chassis SC946L JBOD User's Manual
Optimized for enterprise-level high capacity storage applications, Supermicro's SC946L JBOD
chassis features up to 45 hot-swap 3.5" SAS3 hard drives in top-loading drive bays. It is ideal
for cloud backup, data replication or high density archive storage applications
This design offers extra high-density of HDDs per space ratio in a 4U form factor. The chassis
features high power efficiency, optimized HDD signal trace routing and improved HDD carrier
design to dampen HDD vibrations and maximize performance. Equipped with two redundant
high-efficiency power supplies and five 80 mm high-speed, low-vibration, hot-swappable
cooling fans, the SC946L JBOD is a reliable maintenance storage server.

1.1 Models

Model
SC946LE1C-R1K66JBOD

1.2 Unpacking the System

Inspect the box in which the chassis was shipped. If any equipment appears damaged, file
a claim with the carrier who delivered it.
Chapter 1
Introduction
SC946L JBOD Chassis Models
Drives SAS Expanders
45 SAS/SATA 1
8
Power Supply
1000W/1600W redundant
(Platinum Level)
