Chassis SC946L JBOD User's Manual

3.3 Accessing the Chassis

Drive bays can be accessed by opening the top cover. Other components can be accessed
though the front or rear of the chassis.
Caution: Except for short periods of time, do not operate the server without the cover in
place. It helps provide proper airflow and prevent overheating.
Opening the Drive Cover
On the right side of the chassis, release the two thumb screws and lift the cover. The cover
holds an open position at 100 degrees without additional support. Do not open farther.
Thumb Screws
Figure 3-4. Opening the Drive Cover
38
