Maxon multimax+ User Manual page 71

Local ID Type
Item
Remote ID Type
Private Key Password
Username
Password
IKE Lifetime
If click VPN > IPsec > Tunnel > General Settings, and choose ESP as protocol. The specific parameter
configuration is shown as below.
If choose AH as protocol, the window of SA Settings is displayed as below.
Multimax_user manual_v.4.0.4
Confidential
Select from "Default", "FQDN" and "User FQDN" for IKE negotiation.

Default: Uses an IP address as the ID in IKE negotiation

FQDN: Uses an FQDN type as the ID in IKE negotiation. If this option is
selected, type a name without any at sign (@) for the local security
gateway, e.g., test.robustel.com.

User FQDN: Uses a user FQDN type as the ID in IKE negotiation. If this
option is selected, type a name string with a sign "@" for the local
security gateway, e.g., test@robustel.com.
Description
Select from "Default", "FQDN" and "User FQDN" for IKE negotiation.

Default: Uses an IP address as the ID in IKE negotiation

FQDN: Uses an FQDN type as the ID in IKE negotiation. If this option is
selected, type a name without any at sign (@) for the local security
gateway, e.g., test.robustel.com.

User FQDN: Uses a user FQDN type as the ID in IKE negotiation. If this
option is selected, type a name string with a sign "@" for the local
security gateway, e.g., test@robustel.com.
Enter the private key under the "CA" and "xAuth CA" authentication types.
Enter the username used for the "xAuth PSK" and "xAuth CA" authentication
types.
Enter the password used for the "xAuth PSK" and "xAuth CA" authentication
types.
Set the lifetime in IKE negotiation. Before an SA expires, IKE negotiates a new
SA. As soon as the new SA is set up, it takes effect immediately and the old
one will be cleared automatically when it expires.
IKE Settings
July. 11, 2018
Default
Default
Default
Null
Null
Null
86400
71/139
