Item Description
Index List position –
Interface Show the logical port group this setting applies to. Lan1 is available only if it
was selected by one of ETH0~ETH1 in Ethernet > Ports > Port Settings.
READ ONLY
IP Address Set the IP address assigned to the logical LAN port group.
Netmask Set the Netmask of the logical LAN port group.
MTU Enter the Maximum Transmission Unit.
The window is displayed as below when choosing "Server" as the mode.
Multimax_user manual_v.4.0.4
Confidential
General Settings
READ ONLY
July. 11, 2018
Default
--
--
192.168.0.1
255.255.255.0
1500
