Maxon multimax+ User Manual page 36

Password
Dialup Number
Authentication Type
Switch SIM By Data
Allowance
Data Allowance
Billing Day
Enable
Primary Server
Secondary Server
Interval
Retry Interval
Timeout
Multimax_user manual_v.4.0.4
Confidential
Enter the password for cellular dial-up connection, provided by local ISP.
Enter the dialup number for cellular dial-up connection, provided by local
ISP.
Select from "Auto", "PAP" or "CHAP" as the local ISP required.
Click the toggle button to enable/disable this option. After enabling, it will
switch to another SIM when the data limit reached.
Note: Only used for dual SIM backup.
Set the monthly data traffic limitation. The system will record the data
traffic statistics when data traffic limitation (MiB) is specified. The traffic
record will be displayed in Interface > Link Manager > Status > WWAN
Data Usage Statistics. 0 means disable data traffic record.
Specify the monthly billing day. The data traffic statistics will be
recalculated from that day.
Ping Detection Settings
Click the toggle button to enable/disable the ping detection mechanism, a
keep-alive policy of the router.
Router will ping this primary address/domain name to check that if the
current connectivity is active.
Router will ping this secondary address/domain name to check that if the
current connectivity is active.
Set the ping interval.
Set the ping retry interval. When ping failed, the router will ping again
every retry interval.
Set the ping timeout.
July. 11, 2018
Null
*99***1#
Auto
OFF
0
1
ON
8.8.8.8
114.114.11
4.114
300
5
3
36/139
