Commands Reference - Maxon multimax+ User Manual

band_tdd_lte_2600 TDD
LTE 2600 (band 38)
band_tdd_lte_1900 TDD
LTE 1900 (band 39)
band_tdd_lte_2300 TDD
LTE 2300 (band 40)
band_tdd_lte_2500 TDD
LTE 2500 (band 41)
# set cellular sim 1 phone_number 18620435279
OK
...
# config save_and_apply
OK

5.3 Commands Reference

Commands
Debug
Show
Set
Add
Note: Download the config.XML file from the configured web browser. The command format can
refer to the config.XML file format.
Multimax_user manual_v.4.0.4
Confidential
// save and apply current configuration, make you configuration effect
Syntax
Debug parameters
Show parameters
Set parameters
Add parameters
Description
Turn on or turn off debug function
Show current configuration of each function , if we need to see all
please using "show running "
All the function parameters are set by commands set and add, the
difference is that set is for the single parameter and add is for the list
parameter
July. 11, 2018 135/139
